Technical specifications
| Electrical | |
| Connection type | 3 Phase, 4 Wires, active-neutral, CT-connected |
| Load terminals | Variant-specific, (internal 2A load control) |
| Metrology lamp | Two-configurable metrological LED’s for active and reactive energy |
| Accuracy | Class 1.0 (active energy), Class 2.0 (reactive energy) |
| Compliance | |
| Standards | AS 62052.11, AS 62052.21, AS 62053.21, AS 62053.23, NMI-M6 IEC 62052.11, IEC 62052.21, IEC 62053.21, IEC 62053.23 |
| Power supply | |
| Rated voltage | 230 V, -20% to +15% |
| Rated frequency | 50 Hz ± 5% |
| Current range | 5 A In , 20 A Imax |
| Data storage capacity | |
| Energy / demand load profile | 220 days (per channel) @ 30 minute interval (configurable interval), up to 8 channels |
| Quality of Supply (QoS) parameterse | 90 days (per parameter) @ 30 minute interval (configurable interval), up to 7 parameters Parameters: Avg voltage, current, temperature etc |
| Switches | |
| Auxiliary load control | 2A (build options) |
| Mechanical | |
| Dimensions (W x H x D) | 180 x 221 x 118 mm 180 x 252 x 118 mm (with 35 mm TBC), 180 x 282 x 118 mm (with 65 mm ETBC) |
| Enclosure material | Fire retardant poly-carbonate |
| Weight | 1.9 kg Approx. |
| Sealing provisions | Terminal cover, meter main cover, config button, communications module |
| Display | Liquid Crystal Display (LCD) |
| Mounting Type | Projection |
| Environmental | |
| Temperature | Operating: -10°C to +60°C, Storage: -25°C to +70°C |
| Limit temperature range | -20°C to +70°C |
| Operating humidity | Up to 95% (Non-condensing) |
| Communications | |
| Local communication | IEC optical port (IEC 62056.21) or ANSI optical port (AS 62056.21) |
| Remote communication | LAN, HAN, WAN. Support for most communication topologies Hot-swappable interchangeable modules Sealable separately |
| Outage notification | Reserve power supply (build option) |
