Specification
| Contact rating | (1) Amps 230-240V |
| Contact type | Micro disconnection Voltage Free |
| Supply | AS1/PRT1 – 230V AC 50Hz AS2 – 3 x AA (LR6) batteries |
| Reserve battery type | Lithium battery |
| Pollution degree | Degree 2 |
| Double insulated | Yes |
| Enclosure protection | IP30 |
| Operating temperature range | °C to 40 °C |
| Temperature control range | +5 °C to +30 °C |
| Standby temperature | +5 °C to +10 °C |
| Case material | Thermoplastic flame retardant |
| Dimensions | 120 x 90 x 32 mm |
| Display | Liquid Crystal, back lit |
| Clock | 24 Hour |
| Displayed time adjustments | 1 minute steps |
| Switched time adjustments | 15 minute steps |
| Operating periods | Warm – 3 per day |
| Programme settings | Auto, Standby |
| Override | Instant Warm / Cool |
| Mounting | AS1/PRT1 – 6 pin plate As2 – Standard wall box fixing |
