Specification
| Electrical | |
| Accuracy | Class 0.2s direct mode | Class 0.5s for clamp-on CT mode |
| Voltage input | |
| 3 phase 3 wire | 240 V -30% to +20% |
| 3 phase 4 wire | 240 V -30% to +20% |
| Current range | 1 – 2 A, 5 – 10 A |
| Direct | 1 – 2 A, 5 – 10 A |
| Clamp-On CT | 100 A / 200 A / 300 A / 500 A |
| Mains frequency | 50 Hz ±5% |
| Activity indicator | High intensity red LED |
| Approvals | |
| Certification | S mark |
| Mechanical | |
| Dimensions (WxHxD) | 465 x 350 x 165 mm (approx.) |
| Degree of protection | IP 51 |
| Enclosure | Aluminium |
| Sealing | Sealing on front case |
| Weight | 10.5 kg (approx.) |
| Environmental | |
| Temperature | -10°C to +50°C (operating) |
| Humidity | 95 % non-condensing |
