Product at a glance

i-Credit 500B is a single-phase meter that provides a comprehensive solution for residential and small commercial electricity metering. The meter is extremely versatile and has many features that make it ideal for demand management and tariff metering. Key features include flexible tariff and load profile functions, Quality of Supply (QoS) monitoring, tamper detection and support for high-speed communications for local or remote meter reading.


  • Domestic single-phase premises
  • Small commercial premises
  • Suitable for co-generation metering applications


  • Multiple configurations (up to 12) can be pre-loaded in the meter and executed in the field
  • Minimises stock variants - one type of meter can be deployed in many applications
  • Reduced installation time in existing installations by the use of BAZ fixing footprints
  • Choice of build types and communications options to minimise costs


  • Single-element compact meter
  • Four-quadrant metering
  • Suitable for use as Type 4, 5 or 6 meter
  • 5 TOU energy registers, per channel
  • 4 TOU maximum demand registers, per channel
  • Bidirectional energy registration: import (consumed) and export (generated)
  • User-friendly tariff configurability and intuitive display (LCD)
  • QoS (Quality of Supply) monitoring for voltage and current
  •  Tamper detection for front cover open


Connection type 1-phase, 2-wire, active neutral, direct connected
Measuring elements 1 element
Rated voltage (Vnom) 240 V AC, -20% to +15%
Maximum voltage 415 V (L-N) continuous
4 kV for 1 minute (RJ-45 port)
Impulse withstand 10 kV, 0.5 J
Frequency 50 Hz ±5%
Current range 15 A Ib, 100 A Imax
Accuracy Class 1.0 (Active Energy)
Metrology Lamp Metrological LED, configurable for ANSI Port, (Tx LED)
Standards AS62052.11, AS62052.21, AS62053.21, NMI-M6, AS62054.21, AS62053.23
Dimensions (W x H x D) 135 mm x 195 mm x 78 mm (with 35 mm terminal block cover)
135 mm x 210 mm x 78 mm (with 50 mm terminal block cover)
Enclosure Flame-retardant polycarbonate
Sealing 1 seal on external terminal cover, 1 seal under terminal cover
1 optional seal on left button, 1 seal on secondary terminal cover
Weight 1.1 kg (approx.)
Data Storage Capacity
Energy / Demand Load Profile 395 days (per channel) at 30-minute interval (configurable), up to 4 channels
QoS Parameters 90 days (per parameter) at 30-minute interval (configurable), up to 8 parameters
Parameters: maximum, minimum and average voltage, current, phase angle, temperature
Local ANSI optical port (AS 62056.21)
Remote GSM/GPRS (ECD3x0) modem
RJ-11 peripheral port (option)
Outage Notification Last gasp power supply (build option)
Real-time clock type Crystal or mains-synchronised
Power source Mains supply
Backup Lithium battery, 15-year life
Compliance AS 62054.21
Temperature Operating: -10°C to +60°C
Storage: -25°C to +80°C
Humidity 95%, non-condensing


The success of the Jemena AMI program can, in part, be attributed to Secure’s early commitment to developing a cost effective compliant AMI meter in a market where no such meter existed. Whilst this journey has been challenging, Secure has supported the program from its inception through development, implementation, testing, supply and ongoing support.
Jemena Limited
