Product at a glance

SES 002 is a wired sensor for measuring the surface temperature of hot water flow pipes and hot water tanks in central heating systems. It is optimised for use with SES302 or SES303 to provide accurate temperature information for transmission over a Z-Wave ® network. Up to four SES 002 can be cascaded with each SES302/SES303

Features

  • Accurate surface temperature measurement
  • Optimised for use with SES302, SES303 (links to product pages)
  • Can be cascaded (up to four sensors) with supplied one-meter cable
  • Supplied with thermal pad for optimal heat transfer with metal surfaces
  • Installed on a water tank, using supplied tank housing over-pipe adapter
  • Supplied with one-metre communications cable

Specification

Performance
Measurement range (low) 0 °C to +65 °C
Measurement accuracy (low) ±0.5 °C
Measurement range +66 °C to +100 °C
Measurement accuracy ±1 °C
Mechanical
Dimensions (W x H x D) 20 mm x 79 mm x 24 mm (pipe sensor)
69 mm x 83 mm x 28 mm (tank sensor)
Weight 0.2 kg (approx.)
Case material Flame-retardant thermoplastic
Environmental
Storage temperature -20 °C to +85 °C
Humidity (relative) 0% to 95%
Atmospheric pressure 980 hPA to 1035 hPa
Compliance
Standards IEC 61010-1
