Product at a glance

three element smart meter withcellular communications

Sprint 231 is a single-phase three-element smart meter with three separate measuring elements for independent recording of multiple loads, such as general domestic, solar, hot water or electricvehicle charging (EV). Its field-replaceable communications module enhances flexibility, and makes the utility's investment future-proof. The meter supports firmware upgrade, allowing metering andcommunications features, functionality to be updated in the field. Sprint 231 meters are 'fit for purpose' for all contestable metering installations. This enhances flexibility and makes the investment future-proof. The meters can be used for individualdomestic or small commercial applications, offering value for money with reduced Capex and inventory. The Sprint 231 smartmeter forms part of the Secure's liberty online smart metering solution. Refer liberty online brochure for system details

Application

  • Domestic and small commercial premises
  • Three elements to support independent loads (i.e. solar, hot water, EV) in a single meter
  • Suitable for co-generation metering applications
  • Advanced metering infrastructure (AMI)

Benefits

  • Better information on usage to manage energy consumption
  • Improved billing cycle and accuracy through remote reading
  • Facilitates supply connection/ disconnection remotely
  • Fail-safe installation and commissioning process – reduced site opex and time
  • Power outage management – quick response time
  • Remote re-configurations
  • Reduced cost of ownership
    • Removes cost of manual read
    • Designed to serve long life in field

Features

  • Meets the minimum services specification as per Australian National Electricity Rules (NER)
  • Multi-operator (roaming) SIM support – ensures maximum network coverage
  • Credit and Pay As You Go (PAYG) mode (remotely switchable)
  • Peak and off-peak tariff management
  • Remote de- energisation and energisation
  • Four-quadrant metering with import/export registration•Alerts to identify potential anomalies
  • Quality of supply (QoS) monitoring
  • Modular communication
  • Remote firmware upgrade

Options and accessories

  • Auxiliary load control
  • External antenna
  • Support of home area network (HAN)
  • ZigBee® compliant in-home display

Specification

Electrical
Connection type 1-phase, 2-wire, direct connected
Measuring elements 3 elements
Rated voltage 230 V AC, -20% to +15%
Maximum voltage 460 V (L-N) continuous
Impulse withstand 12 kV, 9 J, as per NMI M6
Frequency 50 Hz ±5%
Current range 10 – 100A
Accuracy Class 1.0 (active energy), class 2.0 (reactive energy)
Metrology Lamp Two configurable metrological LEDs for active and reactive energy
Compliance
Standards NMI M6-1, AS 62052.11, AS 62053.21, AS 62053.23, AS 62052.21
Exceeds minimum services specification as per the National Electricity Amendment (expanding competition in metering and related services. Rule 2015 No. 12)
Data storage capacity
Energy/demand load profile 395 days (per channel) at 30-minute interval (configurable), up to 16 channels,
65 days (per channel) at 5-minute interval (configurable), up to 4 channels
Quality of Supply (QoS) parameters 90 days (per parameter) at 30-minute interval (configurable), up to 16 parameters, including average voltage, current, phase angles, temperature
Switches
Integrated supply/load contactors 3 x 100 A switches
Mechanical
Dimensions (W x H x D) 180 mm x 252 mm x 118 mm
Enclosure Flame-retardant polycarbonate
Sealing provisions Terminal cover, meter main cover, configuration button, communications module
Weight 2.4 kg (approx.), depending on variant
Display 8-character alphanumeric LCD with backlight and icons for status
