Specification
| Electrical | |
| Connection type | 3-phase 4-wires, direct connected |
| Rated voltage | 230 V AC, -20% to +15% |
| Maximum voltage | 460V (L-N) continuous |
| Impulse withstand | 12 kV, 9 J, as per NMI M6 |
| Frequency | 50 Hz ±5% |
| Current range | 10-100A |
| Frequency | 50 Hz ±5% |
| Accuracy class | Class 1.0 (active energy), Class 2.0 (reactive energy) |
| Metrology Lamp | Two configurable metrological LEDs for active and reactive energy |
| Compliance | |
| Standards | NMI M6-1, AS 62052.11, AS 62053.21, AS 62053.23, AS 62052.21Exceeds minimum services specification as per the National Electricity Amendment (expanding competition in metering and related services. Rule 2015 No. 12) |
| Data storage capacity | |
| Energy/demand load profile | 395 days (per channel) at 30-minute interval (configurable), up to 4 channels, 65 days (per channel) at 5-minute interval (configurable), up to 4 channels |
| Quality of Supply (QoS) parameters | 90 days (per parameter) at 30-minute interval (configurable), up to 8 parameters, including average voltage, current, phase angles, temperature |
| Switches/outputs | |
| Mains supply contactor | 100 A |
| Auxiliary load control | 31.5A, variant specific |
| Mechanical | |
| Dimensions (W x H x D) | 180 mm x 252 mm x 118 mm |
| Enclosure material | Flame retardant poly-carbonate |
| Weight | 2.4 kg (approx.) |
| Sealing provisions | Terminal cover, meter main cover, communications module |
| Display | 8-character alphanumeric LCD with backlight and icons for status |
